The GS split-phase hybrid inverter automatically matches mainstream batteries, is UL certified, integrates a breaker, supports two independent battery strings, and features a 200A pass-through with 100% unbalanced load capability.
The GS split-phase hybrid inverter automatically matches mainstream batteries, is UL certified, integrates a breaker, supports two independent battery strings, and features a 200A pass-through with 100% unbalanced load capability.
Product Highlights
Safe and reliable
Support PV reverse polarity protection, Anti-islanding protection, Ground fault protection, Battery reverse protection, Leakage current protection, Insulation resistance detection, Backup output short circuit protection, Arc fault protection, AC output over-current protection
Flexible configuration
UL certified, breaker integrated；
200A pass through, Capable of supporting 100% unbalanced loads.
Convenient operation and maintenance
Automatically matches mainstream batteries, supports remote software upgrades, and is compatible with two independent battery clusters and battery sharing
Choose our benefits
Reduce electricity costs by 50% per year
Free energy available at night
Participate in peak load shifting to gain additional economic benefit
keeping critical load operation in power of
Support 7*24 remote service
Technical Specifications
| Model | R16KH2NA | R18KH2NA | R20KH2NA | R22KH2NA | R24KH2NA |
| PV input data | |||||
| Max. PV input power (kW) | 24 | 27 | 30 | 33 | 36 |
| Max. PV input voltage (V) | 500 | ||||
| Min. PV input voltage (V) | 120 | ||||
| Start-up voltage (V) | 120 | ||||
| MPPT voltage range (V) | 120~500 | ||||
| MPPT voltage range@full-load (V) | 150~430 | ||||
| Rated PV input voltage (V) | 310 | ||||
| No. of MPPT trackers | 4 | ||||
| No. of strings per MPPT tracker | 2/2/2/2 | ||||
| Max. input current per MPPT (A) | 32/32/32/32 | ||||
| Max. short-circuit current per MPPT (A) | 44/44/44/44 | ||||
| Battery input data | |||||
| Battery type | Lithium-ion / Lead-acid | ||||
| Max. charge / discharge power (kW) | 16 | 18 | 20 | 22 | 24 |
| Battery voltage range (V) | 120~400 | ||||
| Battery voltage range@full-load (V) | 160-400 | 180-400 | 200-400 | 220-400 | 240-400 |
| Max. charging / discharging current (A) | 50+50 / 50+50 | ||||
| Rated charge / discharge current (A) | 50+50 / 50+50 | ||||
| Power factor | 0.8 leading - 0.8 lagging | ||||
| Battery charging strategy | Self-adaption to BMS | ||||
| BMS communication | CAN | ||||
| AC output data (grid side) | |||||
| Rated output power (kW) | 16 | 18 | 20 | 22 | 24 |
| Max. apparent output power (kVA) | 16 | 18 | 20 | 22 | 24 |
| Max. apparent input power(kVA) | 16 | 18 | 20 | 22 | 24 |
| Rated grid voltage (V) | 120/240 | ||||
| Grid voltage range (V) | 211~264 | ||||
| Grid input voltage (V) | 240 | ||||
| Rated grid frequency (Hz) | 60 | ||||
| Grid frequency range(Hz) | 58.8~61.2 | ||||
| Rated output current (A) | 66.6 | 75 | 83.3 | 91.6 | 100 |
| Max. AC output current (A) | 66.6 | 75 | 83.3 | 91.6 | 100 |
| Max. apparent input current (A) | 66.6 | 75 | 83.3 | 91.6 | 100 |
| Max. grid passthrough current(A) | 200 | ||||
| Grid type | L1/L2+N+PE | ||||
| AC output data (load side) | |||||
| Rated output power (kW) | 16 | 18 | 20 | 22 | 24 |
| Max. apparent output power (kVA) | 16 | 18 | 20 | 22 | 24 |
| Max. apparent input power(kVA) | 16 | 18 | 20 | 22 | 24 |
| Rated output voltage (V) | 120 / 240 | ||||
| Rated output frequency (Hz) | 60 | ||||
| Rated output current (A) | 66.6 | 75 | 83.3 | 91.6 | 100 |
| Max. AC output current (A) | 200 | ||||
| Back-up switch time (ms) | <20 | ||||
| Protection | |||||
| Supported protection | PV reverse polarity protection, Anti-islanding protection, Ground fault protection, Battery reverse protection,Leakage current protection, Insulation resistance detection, Backup output short circuit protection,Arc fault protection, AC output over-current protection | ||||
| Surge protection | DC Type II / AC Type II | ||||
| Over voltage category | DC Type II / AC Type III | ||||
| General data | |||||
| Ingress protection | IP65 | ||||
| Operating temperature range (℃) | -25~+60 | ||||
| Cooling | FAN cooling | ||||
| Relative humidity | 0-85% | ||||
| Operating altitude (m) | / | ||||
| Dimensions W*D*H (mm) | / | ||||
| Weight (kg) | / | ||||
| Topology (solar / battery) | Transformerless / Transformerless | ||||
| Noise emission (dB) | / | ||||
| Display and communication | |||||
| Display | Touch panel | ||||
| Communication | RS485,CAN,WIFI,4G | ||||
